L<sub>CR</sub>波法的有效检测深度及厚度非均布应力表征方法研究

张春利; 马楠楠; 翁艺林; 朱军; 陈伟球

doi:10.21656/1000-0887.460057

L_CR波法的有效检测深度及厚度非均布应力表征方法研究

doi: 10.21656/1000-0887.460057

1. 浙江大学浣江实验室（诸暨），工程力学系，杭州 310027;
2. 南通泰胜蓝岛海洋工程有限公司，江苏南通 226259

基金项目:

国家自然科学基金重大研究项目（12192210）；国家重点研发计划项目（2020YFA0711701）；浙江省自然科学基金重点项目（LZ25A020007）；浣江实验室 “浣江专项” 研发项目（KM20220616）

详细信息

作者简介:
张春利（1980—），男，教授，博士，博士生导师(通信作者. E-mail: zhangcl01@zju.edu.cn);马楠楠（2000—），男，硕士生(E-mail: 22224089@zju.edu.cn);翁艺林（2001—），男，硕士生(E-mail: 22424081@zju.edu.cn);朱军（1979—），男，正高级工程师（E-mail: zhujun_sloet@163.com）;陈伟球（1969—），男，教授，博士，博士生导师(通信作者. E-mail: chenwq@zju.edu.cn).

通讯作者:
陈伟球（1969—），男，教授，博士，博士生导师(通信作者. E-mail: chenwq@zju.edu.cn).

中图分类号: O343.3
计量
- 文章访问数: 14
- HTML全文浏览量: 3
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2025-03-24
- 修回日期: 2025-04-01
- 网络出版日期: 2026-01-21
- 刊出日期: 2026-01-01

On the Characterization of Effective Detection Depths and Thickness-Direction Inhomogeneous Stresses With the L_{CR_{Wave Method}}

1. Huanjiang Laboratory （Zhuji）, Department of Engineering Mechanics, Zhejiang University, Hangzhou 310027, P.R.China;
2. Nantong Taisheng Blue Island Offshore Co., Ltd., Nantong, Jiangsu 226259, P.R.China

Funds:

The National Science Foundation of China(12192210)

摘要

摘要:
临界折射纵（longitudinal critically refracted wave，简记L_{CR_{）波法在结构应力的无损检测中具有显著优势.然而，L_{CR_{波法目前还缺少符合物理意义、能够有效表征深度入射波激励频率的解析关系，并且无法适用于构件内沿厚度方向非均匀分布应力的测量.为此，导出了L_{CR_{波法测量构件应力分布的有效检测深度与入射波激励频率的解析表达式，提出了一种基于L_{CR_{波法测量构件非均匀应力场的逐级差值算法，并通过数值仿真验证了该算法在非均匀应力测量中的有效性}}}}}}}}
- 临界折射纵波 /
- 应力检测 /
- 有效检测深度 /
- 非均布应力
Abstract:
The longitudinal critically refracted (L_{CR_{) wave method demonstrates significant advantages in non-destructive testing of structural stresses. However, the current L_{CR_{wave technique lacks a physically meaningful analytical relationship between effective detection depths and excitation frequencies of incident waves, and cannot be applied to measure non-uniform stress distributions along the component thickness. To address these limitations, an analytical expression for the correlation between effective detection depths and excitation frequencies in the L_{CR_{wave method-based stress measurements, was derived. A stepwise difference algorithm was proposed for characterizing non-uniform stress fields with the L_{CR_{wave method, and through numerical simulations to validate its effectiveness in measuring inhomogeneous stress distributions.}}}}}}}}
- longitudinal critically refracted wave /
- stress detection /
- effective detection depth /
- inhomogeneous stress

HTML全文

参考文献(39)

[2]BERA T, MOHANTY S. A review on residual stress in metal additive manufacturing[J].3D Printing and Additive Manufacturing,2024,11(4): 1462-1470.

JIANG Xiaohui, WEI Yuxi, ZHOU Jinhua, et al. Residual stress generation and evaluation in milling: a review[J].The International Journal of Advanced Manufacturing Technology,2023,126: 3783-3812.

[3]JANDERA M, MACHACEK J. Residual stress influence on material properties and column behaviour of stainless steel SHS[J].Thin-Walled Structures,2014,83: 12-18.

[4]MA Yuan, ZHANG Jianfu, FENG Pingfa, et al. Study on the evolution of residual stress in successive machining process[J].The International Journal of Advanced Manufacturing Technology,2018,96: 1025-1034.

[5]DAMJANOVIC D, KOZAK D, GUBELJAK N. The influence of residual stresses on fracture behavior of pipe ring notched bend specimen (PRNB)[J].Engineering Fracture Mechanics,2019,205: 347-358.

[6]KHALIFAH L M, AZIZ I A, IBRAHIM S J. Defects and residual stresses effect on the functional performance of a 106 pipes after the welding process[J].Welding International,2024,38(1): 1-12.

[7]LI Zhihui, ZHENG Xinqian. Review of design optimization methods for turbomachinery aerodynamics[J].Progress in Aerospace Sciences,2017,93: 1-23.

[8]ZHANG Qinglong, YU Lei, SHANG Xiaofeng, et al. Residual stress relief of welded aluminum alloy plate using ultrasonic vibration[J].Ultrasonics,2020,107: 106164.

[9]ZHAN Yu, XU Hexuan, DU Wenqiang, et al. Research on the influence of heat treatment on residual stress of TC4 alloy produced by laser additive manufacturing based on laser ultrasonic technique[J].Ultrasonics,2021,115: 106466.

[10]XU Chunguang, TIAN Haibing, SONG Wentao, et al. Ultrasonic non-destructive testing and in situ regulation of residual stress[J].Materials Research Proceedings,2017,2: 241-246.

[11]SHAO Zhaoyu, ZHANG Chengcheng, LI Yankai, et al. A review of non-destructive evaluation (NDE) techniques for residual stress profiling of metallic components in aircraft engines[J].Aerospace,2022,9(10): 534.

[12]HABIBALAHI A, SAFIZADEH M S. Forward to residual stress measurement by using pulsed eddy current technique[J].Insight: Non-Destructive Testing and Condition Monitoring,2013,55(9): 492-497.

[13]陈荟键, 朱清锋, 苗鸿臣, 等. 受载结构中SH_{0_{波与裂纹作用的非线性散射场的数值研究[J]. 应用数学和力学, 2023,44(4): 367-380.(CHEN Huijian, ZHU Qingfeng, MIAO Hongchen, et al. Numerical study of nonlinear scattering characteristics of SH_{0_{waves encountering cracks in prestressed plates[J].Applied Mathematics and Mechanics,2023,44(4): 367-380. (in Chinese))}}}}

[14]王喜顺, 郭昊, 朱清锋, 等. 钢-环氧-钢三明治结构胶层缺陷的导波检测方法研究[J]. 应用数学和力学, 2024,45(11): 1416-1427.(WANG Xishun, GUO Hao, ZHU Qingfeng, et al. A guided-wave-based method for detecting defects in the adhesive layer of the steel-epoxy-steel sandwich structure[J].Applied Mathematics and Mechanics,2024,45(11): 1416-1427. (in Chinese))

[15]QIU Hao, CHEN Mingtong, LI Faxin. An omnidirectional piezoelectric transducer for selective excitation and reception of high-order shear horizontal waves[J].Ultrasonics,2022,124: 106731.

[16]WANG Danfeng, CHUANG Kuochih, LIU Junjie, et al. Modeling full-field transient flexural waves on damaged plates with arbitrary excitations using temporal vibration characteristics[J].Sensors,2022,22(16): 5958.

[17]HE Jingbo, LI Zuohua, TENG Jun, et al. Absolute stress field measurement in structural steel members using the Lcr wave method[J].Measurement,2018,122: 679-687.

[18]PEI Ning, ZHAO Bin, ZHAO Xin, et al. Analysis of the directivity of longitudinal critically refracted (LCR) waves[J].Ultrasonics,2021,113: 106359.

[19]YANG Xinhua, DING Jiexiong, LIU Fan, et al. Study of transmitting and receiving in longitudinal stress measurement with the LCR wave[C]//2006 International Conference on Mechatronics and Automation.Luoyang: IEEE, 2006.

[20]CHAKI S, KE W, DEMOUVEAU H. Numerical and experimental analysis of the critically refracted longitudinal beam[J].Ultrasonics,2013,53(1): 65-69.

[21]LI Zuohua, HE Jingbo, TENG Jun, et al. Cross-correlation-based algorithm for absolute stress evaluation in steel members using the longitudinal critically refracted wave[J].International Journal of Distributed Sensor Networks,2018,14(10). DOI: 10.1177/1550147718803312.

[22]JAVADI Y, AKHLAGHI M, NAJAFABADI M A. Using finite element and ultrasonic method to evaluate welding longitudinal residual stress through the thickness in austenitic stainless steel plates[J].Materials & Design,2013,45: 628-642.

[23]LI Yukun, YU Wenguang, LIU Li, et al. A novel method for evaluating biaxial stresses by ultrasonic critical refracted longitudinal waves[J].Journal of Testing and Evaluation,2020,48(4): 2597-2610.

[24]MA Ting, XU Guocheng, DONG Juan, et al. Simulation and experiment of complex residual stress detection of metal plate based on critical refracted longitudinal wave (LCR) method[J].NDT & E International,2024,146: 103157.

[25]LEON-SALAMANCA T, BRAY D F. Residual stress measurement in steel plates and welds using critically refracted longitudinal (LCR) waves[J].Research in Nondestructive Evaluation,1996,7: 169-184.

[26]BRAY D E, TANG W, GREWAL D S. Ultrasonic stress evaluation in a compressor rotor[J].Journal of Testing and Evaluation,1997,25(5): 503-509.

[27]SONG Wentao, PAN Qinxue, XU Chunguang, et al. Residual stress nondestructive testing for pipe component based on ultrasonic method[C]//2014 IEEE Far East Forum on Nondestructive Evaluation/Testing.Chengdu: IEEE, 2014: 163-167.

[28]JAVADI Y, KROLCZYK G M, HLOCH S. Evaluation of hoop residual stress variations in the thickness of dissimilar welded pipes by using the LCR ultrasonic waves[J].Tehnicki Vjesnik: Technical Gazette,2016,23(2): 329-335.

[29]FRAGA R S, SANTOS A A, ANDRINO M H. Temperature effect on the measurement of stresses in pipelines using ultrasonic Lcr waves[C]//2008 ASME International Mechanical Engineering Congress and Exposition,Boston, MA: ASME, 2008.

[30]MOHAMMADI M, FESHARAKI J J. Determination of acoustoelastic/acoustoplastic constants to measure stress in elastic/plastic limits by using LCR wave[J].NDT & E International,2019,104: 69-76.

[31]WANG X, TAO C H, SHI Y W, et al. Non-destructive evaluation of non-uniform stress fields and subsurface stress gradients using ultrasonic waves[J].Materials Research Innovations,2014,18(S4): 1091-1094.

[32]DJERIR W, OURAK M, BOUTKEDJIRT T. Characterization of the critically refracted longitudinal (LCR) waves and their use in defect detection[J].Research in Nondestructive Evaluation,2014,25(4): 203-217.

[33]LU Yuren, XU Chunguang, PAN Qinxue, et al. Research on an ultrasonic longitudinal critically refracted wave detection method for the depth distribution of stress[J].Metals,2022,12(10): 1602.

[34]LIU Yongmeng, LIU Enxiao, CHEN Yuanlin, et al. Study on propagation depth of ultrasonic longitudinal critically refracted (LCR) wave[J].Sensors,2020,20(19): 5724.

[35]XU Chunguang, SONG Wentao, PAN Qinxue, et al. Nondestructive testing residual stress using ultrasonic critical refracted longitudinal wave[J].Physics Procedia,2015,70: 594-598.

[36]SONG Wentao, XU Chunguang, PAN Qinxue, et al. Nondestructive testing and characterization of residual stress field using an ultrasonic method[J].Chinese Journal of Mechanical Engineering,2016,29(2): 365-371.

[37]JUNGE M, QU J, JACOBS L J. Relationship between Rayleigh wave polarization and state of stress[J].Ultrasonics,2006,44(3): 233-237.

[38]EGLE D M, BRAY D E. Measurement of acoustoelastic and third-order elastic constants for rail steel[J].The Journal of the Acoustical Society of America,1976,60(3): 741-744.

[39]杨桂通, 张善元. 弹性动力学[M]. 北京: 中国铁道出版社, 1988.(YANG Guitong, ZHANG Shanyuan.Elastodynamics[M]. Beijing: China Railway Publishing House, 1988. (in Chinese))
