海上油气田消除严重段塞流的节流模型研究

许路寒; 闫伊玮; 吴全红; 杜耀华; 王寒玄; 邹遂丰

doi:10.21656/1000-0887.460140

海上油气田消除严重段塞流的节流模型研究

doi: 10.21656/1000-0887.460140

1. 西安交通大学动力工程多相流国家重点实验室，西安 710049;
2. 龙源（北京）新能源工程技术有限公司，北京 100034;
3. 国家能源风电运营技术研发（实验）中心，西安 710309

基金项目:

国家重点研发计划（2022YFC2806202）；中央高校基本科研业务费（xtr042024002）

详细信息

作者简介:
许路寒（2001— ），男，硕士(E-mail: xuluhan@stu.xjtu.edu.cn);邹遂丰（1990— ），男，高级工程师，博士(通信作者. E-mail: zou_suifeng@xjtu.edu.cn).

通讯作者:
邹遂丰（1990— ），男，高级工程师，博士(通信作者. E-mail: zou_suifeng@xjtu.edu.cn).

中图分类号: O359
计量
- 文章访问数: 11
- HTML全文浏览量: 2
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-08-01
- 修回日期: 2026-05-11
- 网络出版日期: 2026-07-03
- 刊出日期: 2026-06-01

Study on the Choking Model for Elimination of Severe Slugging in Offshore Oil and Gas Fields

1. State Key Laboratory of Multiphase Flow in Power Engineering, Xi’an Jiaotong University, Xi’an 710049, P.R. China;
2. Longyuan (Beijing) New Energy Engineering Technology Co., Ltd., Beijing 100034, P.R. China;
3. National Energy Wind Power Operation Technology R&D Center, Xi’an 710309, P.R. China

摘要

摘要: 为预测以节流方式消除海上油气立管系统严重段塞流所需的阀门开度，开展室内模型实验研究.基于流型转变时立管顶部液塞流出时刻的瞬时单相流的特性，得出了抑制气液喷发所需的节流压降和阻力系数需满足的条件——节流阀压降峰值与瞬时单相流动相对应，在严重段塞流恰好消除时可取为均值的2倍.进而按定义依次求出目标阻力系数和流量系数，最后按阀门出厂或实际标定的流量特性求出开度.本预测模型避免了传统模型中两相平均参数与单相阀门特性映射不一致的问题，在150 m/DN 50与380 m/DN 80两套实验环路上的预测开度平均偏差分别为+0.55%与+1.8%；油田开度预测结果与自动控制实操偏差不超过±2%.构建的模型既可用于指导现场人工调控，也可为自动调控的目标参数设定提供参考.
- 两相流动 /
- 严重段塞流 /
- 顶部节流 /
- 阻力系数
Abstract: Laboratory experiments were performed to establish a model for predicting the valve opening of the topside choking method for elimination of severe slugging in offshore oil and gas pipeline-riser systems. Based on the outflow characteristics of liquid slug at the riser top at the flow regime transition, which can be regarded as those of transient single-phase liquid flow, the condition for gas-liquid blowout mitigation was determined, i.e. the peak value of pressure drop across the valve shall be twice its time-average value just at the elimination moment of severe slugging, corresponding to the transient single-phase liquid flow. Then, the target resistant factor and the flow coefficient were derived successively according to the defined equations. Finally, the valve opening was worked out according to either the specification document of the valve or the calibration of the flow characteristics of the valve. The prediction model innovatively correlates the peak pressure drop across the choke valve with the physical process of instantaneous single-phase flow, resolving the inconsistency of mapping averaged 2-phase parameters to single-phase valve characteristics in conventional models. The average deviation of prediction for 2 experimental loops (150-m/DN 50 and 380-m/DN 80) is +0.55% and +1.8%, respectively, for experimental data from 2 experimental pipelines; while the deviation from automatic control result is smaller than ±2% in a field case. The established model can guide manual operations and serve as a setpoint for automatic control systems in offshore fields.
- 2-phase flow /
- severe slugging /
- topside choking /
- resistant factor

HTML全文

参考文献(29)

LI X, XUE Y, DU H, et al. Investigation on leakage detection and localization in gas-liquid stratified flow pipelines based on acoustic method[J].Journal of Pipeline Science and Engineering,2022,2(4): 100089.

[2]SCHMIDT Z. Experimental study of two-phase slug flow in a pipeline-riser pipe system[D]. Tulsa, USA: The University of Tulsa, 1977.

[3]MALEKZADEH R, HENKES R A W M, MUDDE R F. Severe slugging in a long pipeline-riser system: experiments and predictions[J].International Journal of Multiphase Flow,2012,46: 9-21.

[4]BANJARA V, PEREYRA E, AVILA C, et al. Improved severe slugging modeling and mapping[J].Geoenergy Science and Engineering,2025,244: 213446.

[5]LIU T, ZOU S, WANG H, et al. Cyclic flow cut-off characteristics of gas-liquid two-phase flow in pipeline-riser system and prediction of its occurring condition[J].International Journal of Multiphase Flow,2025,182: 105042.

[6]张西迎, 李乃良, 陈冰清. 文昌油田集输-S形立管内严重段塞流的分析与控制[J]. 油气储运, 2019,38(4): 472-480.(ZHANG Xiying, LI Nailiang, CHEN Bingqing. Analysis and treatment on the severe slug flow in pipeline S-shaped riser of Wenchang Oilfield[J].Oil & Gas Storage and Transportation,2019,38(4): 472-480. (in Chinese))

[7]PEDERSEN S, DURDEVIC P, YANG Z. Challenges in slug modeling and control for offshore oil and gas productions: a review study[J].International Journal of Multiphase Flow,2017,88: 270-284.

[8]李清平, 姚海元, 程兵. 深水流动安全保障技术[M]. 上海: 上海科学技术出版社, 2021: 1-7. （LI Qingping, YAO Haiyuan, CHENG Bing, et al.Flow Assurance for Deepwater Oil and Gas Fields[M]. Shanghai: Shanghai Scientific and Technical Publishers, 2021: 1-7. (in Chinese)）

[9]HENRIOT V, COURBOT A, HEINTZ E, et al.Simulation of process to control severe slugging: application to the Dunbar pipeline[C]//SPE Annual Technical Conference and Exhibition.Houston, Texas. Richardson: Society of Petroleum Engineers, 1999: SPE-56461-MS.

[10]HAVRE K, DALSMO M. Active feedback control as a solution to severe slugging[J].SPE Production & Facilities,2002,17(3): 138-148.

[11]陈学锋. SZ36-1油田海管段塞流处理技术研究[D]. 成都: 西南石油学院, 2005.（CHEN Xuefeng. Study on solution to slugging in offshore pipeline in SZ36-1 oil field[D]. Chengdu: Southwest Petroleum Institute, 2005. (in Chinese)）

[12]姜安, 宁永庚. 渤南油气田海底管道段塞流对友谊号原油处理流程的影响及防止措施[J]. 石油天然气学报, 2008,30(2): 351-353. （JIANG An, NING Yonggeng. Influence of slugging in subsea pipeline on the process of crude oil in “Bohai Youyi” fpso in bonan oil and gas field and preventive measures[J].Journal of Oil and Gas Technology,2008,30(2): 351-353. (in Chinese)）

[13]李忠亮, 罗京, 卢进良. BZ25-1油田段塞流影响分析和应对措施的应用[J]. 中国造船, 2012,53(S2): 310-315.(LI Zhongliang, LUO Jing, LU Jinliang. Application and analysis about affection and treatment of slug flow in BZ25-1 oil field[J].Shipbuilding of China,2012,53(S2): 310-315. (in Chinese))

[14]郭庆丰. 严重段塞流对JZ25-1S油田群生产的影响及对策[J]. 中国海洋平台, 2014,29(6): 5-9.(GUO Qingfeng. The influence of sever slugging to the production of JZ25-1S oilfield group and its countermeasures[J].China Offshore Platform,2014,29(6): 5-9. (in Chinese))

[15]李长俊, 吴畏, 张黎. 渤西油田严重段塞流控制措施数值模拟[J]. 油气储运, 2018,37(1): 95-100.(LI Changjun, WU Wei, ZHANG Li. Numerical simulation on control measures of severe slug flow in Boxi Oilfield[J].Oil & Gas Storage and Transportation,2018,37(1): 95-100. (in Chinese))

[16]NNABUIFE S G, TANDOH H, WHIDBORNE J F. Slug flow control using topside measurements: a review[J].Chemical Engineering Journal Advances,2022,9: 100204.

[17]OGAZI A. Multiphase severe slug control[D]. Cranfield, UK: Cranfield University, 2011.

[18]JAHANSHAHI E, SKOGESTAD S. Simplified dynamical models for control of severe slugging in multiphase risers[J].IFAC Proceedings Volumes,2011,44(1): 1634-1639.

[19]PARK K H, KIM T W, KIM Y J, et al. Experimental investigation of model-based IMC control of severe slugging[J].Journal of Petroleum Science and Engineering,2021,204: 108732.

[20]WANG H, ZOU S, LIU T, et al. Experimental investigation of online solving for critical valve opening for eliminating severe slugging in pipeline-riser systems[J].International Journal of Heat and Fluid Flow,2024,110: 109584.

[21]TAITEL Y. Stability of severe slugging[J].International Journal of Multiphase Flow,1986,12(2): 203-217.

[22]JANSEN F E, SHOHAM O, TAITEL Y. The elimination of severe slugging: experiments and modeling[J].International Journal of Multiphase Flow,1996,22(6): 1055-1072.

[23]FADAIRO A, OBI C, LING K, et al. An improved model for severe slugging stability criteria in offshore pipeline-riser systems[J].Petroleum Research,2022,7(3): 318-328.

[24]FU J, WU Q, SUN J, et al. The prediction of the valve opening required for slugging control in offshore pipeline risers based on empirical closures and valve characteristics[J].Journal of Marine Science and Engineering,2025,13(5): 981.

[25]ZOU S, YAO T, GUO L, et al. Non-uniformity of gas/liquid flow in a riser and impact of operation and pipe configuration on slugging characteristics[J].Experimental Thermal and Fluid Science,2018,96: 329-346.

[26]孔祥伟, 林元华, 邱伊婕, 等. 气侵钻井过程中井底衡压的节流阀开度控制研究[J]. 应用数学和力学, 2014,35(5): 572-580.(KONG Xiangwei, LIN Yuanhua, QIU Yijie, et al. Research on the throttle valve opening degree control to keep bottomhole pressure in balance when gas influx occurs during drilling operations[J].Applied Mathematics and Mechanics,2014,35(5): 572-580. (in Chinese))

[27]杨鹏飞, 毛良杰, 杨森, 等. 基于井筒多相流理论的复杂结构井动态压井过程中的井筒压力研究[J]. 应用数学和力学, 2025,46(2): 254-270.(YANG Pengfei, MAO Liangjie, YANG Sen, et al. Research on wellbore pressure in the dynamic killing process for complex structure wells based on the wellbore multiphase flow theory[J].Applied Mathematics and Mechanics,2025,46(2): 254-270. (in Chinese))

[28]SHI H, HOLMES J A, DURLOFSKY L J, et al. Drift-flux modeling of two-phase flow in wellbores[J].SPE Journal,2005,10(1): 24-33.

[29]许路寒, 杨博, 邹遂丰, 等. 节流阀安装位置对严重段塞流调控效果影响研究[C]//2024年中国工程热物理学会多相流学术会议论文集. 天津: 中国工程热物理学会, 2024: 65-036.（XU Luhan, YANG Bo, ZOU Suifeng, et al. Study on effects of valve installation position on control of severe slugging control[C]//Proceedings of 2024 CSET Multiphase Flow Conference.Tianjin: Chinese Society of Engineering Thermophysics, 2024: 65-036. (in Chinese)）
