小流量工况下汽轮机低压缸流动换热特性分析

王新龙; 刘众元; 张嘉杰; 马素霞; 李勇; 屈治国

doi:10.21656/1000-0887.460162

小流量工况下汽轮机低压缸流动换热特性分析

doi: 10.21656/1000-0887.460162

王新龙¹,
刘众元²,
张嘉杰^1,2, ,,
马素霞^1,2,
李勇¹,
屈治国³

1. 太原理工大学电气与动力工程学院，太原 030024;
2. 怀柔实验室山西研究院，太原 030032;
3. 西安交通大学能源与动力工程学院热流科学与工程教育部重点实验室，西安 710049

基金项目:

山西省科技重大专项（202201090301001）

详细信息

作者简介:
王新龙（2000—），男，硕士生(E-mail: 18919044734@163.com);张嘉杰(1988—），男，教授，博士(通信作者. E-mail: zhangjiajie@tyut.edu.cn).

通讯作者:
张嘉杰(1988—），男，教授，博士(通信作者. E-mail: zhangjiajie@tyut.edu.cn).

中图分类号: TK26
计量
- 文章访问数: 11
- HTML全文浏览量: 2
- PDF下载量: 4
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-04
- 修回日期: 2025-11-15
- 网络出版日期: 2026-07-23

Analysis of Flow and Heat Transfer Characteristics in the Steam Turbine Low-Pressure Cylinder Under Low Flow Conditions

1. College of Electrical and Power Engineering, Taiyuan University of Technology,Taiyuan 030024, P.R. China;
2. Shanxi Research Institute of Huairou Laboratory, Taiyuan 030032, P.R. China;
3. Key Laboratory of ThermoFluid Science and Engineering, MOE,School of Energy and Power Engineering, Xi’an Jiaotong University, Xi’an 710049, P.R. China

摘要

摘要: 随着供热机组普遍实施低压缸零出力改造，汽轮机低压缸经常需要在极低流量下运行.为深入理解这一工况下的流动行为，本研究以某电厂汽轮机低压缸为例，构建了末级流道的数值计算模型，通过仿真分析变工况特别是小流量条件下缸内流动状态与气动性能，着重观察了末级流场结构和动叶片表面的温度变化.研究发现，在小流量运行时，低压缸末级内会发生气流分离和回流，分离最初出现在动叶根部，随着流量降低逐渐向叶顶蔓延.通道内生成局部涡流，动叶进口处出现负攻角，对蒸汽的正常流动形成明显阻碍.当负荷下降至15%THA(即额定负荷的15%)时，末级静叶顶端出汽边开始出现局部高温区，显示出鼓风加热效应；随着流量进一步减少，高温区域不断扩大，最高温度持续上升.在负荷降至10%THA时，动叶表面最高温度相比额定工况上升了40.29%.该研究为实施零出力改造后的供热机组低压缸安全运行提供了参考依据.
- 小流量 /
- 低压缸流场 /
- 鼓风加热 /
- 喷水减温
Abstract: With the widespread implementation of zero-output transformation of low-pressure cylinders in heating units, the low-pressure cylinders of steam turbines often need to operate at extremely low flow rates. To get a deeper understanding of the flow behavior under this working condition, the low-pressure cylinder of a steam turbine in a certain power plant was studied, a numerical calculation model for the final-stage flow channel was constructed, and the structure of the final-stage flow field and the temperature changes on the surface of the moving blades were inspected through simulation analysis of the flow state and aerodynamic performance in the cylinder under variable working conditions, especially at low flow rates. The research results indicate that, at low flow rates, the gas separation and backflow will occur in the final stage of the low-pressure cylinder. The separation initially occurs at the moving blade root and gradually spreads to the blade top as the flow rate decreases. Local vortices emerge in the channel, and a negative attack angle appears at the moving blade inlet, which significantly hinders the normal steam flow. When the load drops to 15%THA, a local high-temperature zone will appear at the steam outlet edge on the top of the last stage stator blade, showing the blower heating effect. As the flow rate further decreases, the high-temperature area will keep expanding and the maximum temperature will continue to rise. When the load decreases to 10%THA, the maximum surface temperature of the moving blade will rise by 40.29% compared with the rated working condition. This research provides a reference basis for the safe operation of the low-pressure cylinder of the heating unit after the zero-output transformation.
- small flow /
- low-pressure cylinder flow field /
- windage heating /
- spray attemperation

HTML全文

参考文献(21)

[2]刘吉臻. 大规模新能源电力安全高效利用基础问题[J]. 中国电机工程学报, 2013,33(16): 1-8. (Liu Jizhen. Basic issues of the utilization of large-scale renewable power with high security and efficiency[J].Proceedings of the CSEE,2013,33(16): 1-8. (in Chinese))

Huang D. Models of steam force and torque of a rotor subjected to the leakage of tip clearance[J].Proceedings of the Institution of Mechanical Engineers (Part A):Journal of Power and Energy,2002,216(5): 355-361.

[3]Ge L J, Zhang C H, Hao M, et al. Vibration analysis of the steam turbine shafting caused by steam flow[J].TELKOMNIKA Indonesian Journal of Electrical Engineering,2013,11(8): 23-43.

[4]徐鹏, 胡辉. 小流量工况下汽轮机末级定常流动特性数值研究[J]. 南方农机, 2021,52(21): 86-88. (Xu Peng, Hu Hui. Numerical study on the steady flow characteristics of the final stage of steam turbine under low flow conditions[J].China Southern Agricultural Machinery,2021,52(21): 86-88. (in Chinese))

[5]石红晖, 张攀, 曹蓉秀, 等. 小流量条件下低压缸末级流动特性研究[J]. 动力工程学报, 2022,42(2): 109-114. (Shi Honghui, Zhang Pan, Cao Rongxiu, et al. Investigations on the flow characteristics of the last stage of the low-pressure cylinder under small flow rate conditions[J].Journal of Chinese Society of Power Engineering,2022,42(2): 109-114. (in Chinese))

[6]谈晓辉, 张奔, 王耀文, 等. 小流量工况下汽轮机低压缸内流动与鼓风加热特性数值研究[J]. 汽轮机技术, 2022,64(6): 445-450. (Tan Xiaohui, Zhang Ben, Wang Yaowen, et al. Numerical study on flow and windage heating characteristics in low pressure cylinder of steam turbine under small mass flow conditions[J].Turbine Technology,2022,64(6): 445-450. (in Chinese))

[7]Teufelberger A. Ventilation von dampfturbinen bei schwachlast, leerlauf und leistungsaufnahme[J].VDI Berichte,1980,361: 145-152.(in German)

[8]徐佳敏. 深度调峰工况下600 MW汽轮机低压缸流场数值计算与分析[J]. 汽轮机技术, 2020,62(3): 167-169. (Xu Jiamin. Numerical calculation and analysis of flow field of low pressure cylinder of 600 MW steam turbine in depth peak load conditions[J].Turbine Technology,2020,62(3): 167-169. (in Chinese))

[9]齐晗兵, 陈勇, 张德实, 等. 掠高对涡轮静叶栅气动性能的影响[J]. 流体机械, 2008,36(11): 23-27.(Qi Hanbing, Chen Yong, Zhang Deshi, et al. Influence of swept height on turbine static cascade aerodynamics[J].Fluid Machinery,2008,36(11): 23-27. (in Chinese))

[10]郭瑞, 杨建刚, 曹浩, 等. 偏心及部分进汽下密封间隙流体激振力数值研究[J]. 流体机械, 2011,39(1): 20-24. (Guo Rui, Yang Jiangang, Cao Hao, et al. Numerical investigation of seal clearance flow excited force under eccentricity and the partial admission mode[J].Fluid Machinery,2011,39(1): 20-24. (in Chinese))

[11]Troyanovskii B, Lagun V, Maiorskii E, et al. Designing steam turbine last stages[J].Teploenergetika,1970(17): 16-20.

[12]马建伟. 超低负荷多级湿蒸汽透平非定常气动特性的数值研究[D]. 哈尔滨: 哈尔滨工业大学, 2020. (Ma Jianwei. Numerical study on unsteady aerodynamic characteristics of ultra-low load multi-stage wet steam turbine[D]. Harbin: Harbin Institute of Technology, 2020. (in Chinese))

[13]陆传根, 林兴华. 流体机械叶片的频率测试及可靠性分析[J]. 流体机械, 2004,32(9): 36-37. (Lu Chuangen, Lin Xinghua. Reliability analysis and frequency test of fluid mechanical blade[J].Fluid Machinery,2004,32(9): 36-37. (in Chinese))

[14]王加兴. 小流量工况下汽轮机末级叶片安全性分析[D]. 吉林: 东北电力大学, 2021. (Wang Jiaxing. Safety analysis of the final stage blades of steam turbines under low flow conditions[D]. Jilin: Northeast Electric Power University, 2021. (in Chinese))

[15]曹丽华, 张浩龙, 林文斌, 等. 汽轮机排汽通道内湿蒸汽流动的数值研究[J]. 热能动力工程, 2015,30(3): 387-393. (Cao Lihua, Zhang Haolong, Lin Wenbin, et al. Numerical study of the wet steam flow in the steam exhaust passage of a steam turbine[J].Journal of Engineering for Thermal Energy and Power,2015,30(3): 387-393. (in Chinese))

[16]徐美超. 小容积流量下汽轮机末级叶片动力特性研究[D]. 吉林: 东北电力大学, 2021. (Xu Meichao. Study on dynamic characteristics of the last stage blade of steam turbine under low volume flow conditions[D]. Jilin: Northeast Electric Power University, 2021. (in Chinese))

[17]陈昆. 汽轮机低压缸零出力运行通流部分的鼓风工况与冷却安全性研究[D]. 济南: 山东大学, 2023.(Chen Kun. Research on the windage condition and cooling safety of the flow passage of the low-pressure cylinder of zero-output operation steam turbine[D]. Jinan: Shandong University, 2023. (in Chinese))

[18]Filippenko V, Frolov B, Chernobrovkin A, et al. Analyses of temperature distribution on steam turbine last stage low pressure buckets at low flowoperations[C]//ASME 〖STBX〗2011 Turbo Expo: Turbine Technical Conference and Exposition. Vancouver, British Columbia, Canada: ASMEDC, 2011: 2463-2469.

[19]徐美超, 曹丽华, 司和勇, 等. 汽轮机低压缸喷水减温对末级叶片气动性能和强度性能的影响[J]. 中国电机工程学报, 2021,41(7): 2446-2454. (Xu Meichao, Cao Lihua, Si Heyong, et al. Effect of water spray in exhaust passage of steam turbine on aerodynamic and strength performance of the last stage blade[J].Proceedings of the CSEE,2021,41(7): 2446-2454. (in Chinese))

[20]侯丽娜, 杜刚, 陈江. 引气方式对轴流压气机性能影响研究[J]. 应用数学和力学, 2014,35(10): 1124-1134. (Hou Lina, Du Gang, Chen Jiang. Effects of bleeding on the aerodynamic performance of axial-flow compressors[J].Applied Mathematics and Mechanics,2014,35(10): 1124-1134. (in Chinese))

[21]姚明辉, 王兴志, 吴启亮, 等. 基于RBF神经网络的压气机叶片面压力场预测研究[J]. 应用数学和力学, 2023,44(10): 1187-1199. (Yao Minghui, Wang Xingzhi, Wu Qiliang, et al. RBF neural network based prediction on blade surface pressure fields in compressors[J].Applied Mathematics and Mechanics,2023,44(10): 1187-1199. (in Chinese))
