循环流化床锅炉水冷壁热应力影响因素分析

高义斌; 左琪; 张浩; 樊尊硕; 李勇; 徐婧

doi:10.21656/1000-0887.460177

循环流化床锅炉水冷壁热应力影响因素分析

doi: 10.21656/1000-0887.460177

高义斌¹,
左琪¹,
张浩¹,
樊尊硕²,
李勇²,
徐婧^2, ,

1. 国网山西省电力有限公司电力科学研究院，太原 030001;
2. 太原理工大学电气与动力工程学院，太原 030024

基金项目:

国网山西省电力公司科技项目（520530250004）

详细信息

作者简介:
高义斌（1979—），男，正高级工程师，硕士(E-mail: gaoyibin2004@126.com);徐婧（1989—），女，副教授，博士(通信作者. E-mail: xujing@tyut.edu.cn).

通讯作者:
徐婧（1989—），女，副教授，博士(通信作者. E-mail: xujing@tyut.edu.cn).

中图分类号: O351
计量
- 文章访问数: 20
- HTML全文浏览量: 8
- PDF下载量: 2
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-24
- 修回日期: 2025-12-17
- 网络出版日期: 2026-07-30
- 刊出日期: 2026-08-01

Influencing Factors on the Water-Cooled Wall Thermal Stress in CFB Boilers

Gao Yibin¹,
Zuo Qi¹,
Zhang Hao¹,
Fan Zunshuo²,
Li Yong²,
Xu Jing^{2
, ,}

1. State Grid Shanxi Electric Power Company Electric Power Research Institute Taiyuan, Taiyuan 030001, P.R. China;
2.College of Electrical and Power Engineering, Taiyuan University of Technology, Taiyuan 030024, P.R. China

摘要

摘要: 本文以某在役超临界循环流化床（circulating fluidized bed, CFB）锅炉为研究对象，结合实际运行数据，构建其温度场与应力场的仿真模型，探讨了管壁外热流密度、对流传热系数等边界条件对水冷壁管最高温度与最大热应力的影响规律，分析了鳍片厚度、管间节距等结构参数对相邻水冷壁管最大温差与最大热应力的影响.仿真结果表明：当对流换热系数一定时，水冷壁管的最高壁温与最大热应力随着管外壁热流密度的增大而增大；当管外壁热流密度一定时，水冷壁管的最高温度与最大热应力随着管壁与工质间对流换热系数的增大而减小；当换热系数降低至0.5 kW/(m²·K) 时，最大热应力迅速增大，相邻水冷壁管的最大温差及最大热应力会随着鳍片厚度的减小而增大，但会随着管间节距的增大而增大.当鳍片厚度减少2 mm时，相邻水冷壁管的最大温差可升高约5 ℃，对应的最大热应力由213 MPa升高至219 MPa；当管间节距增加2 mm时，相邻水冷壁管的最大温差可升高7 ℃，对应的最大热应力由213.8 MPa升高至215.1 MPa.
- 循环流化床锅炉 /
- 水冷壁 /
- 数值模拟 /
- 壁温 /
- 热应力
Abstract: The in-service supercritical circulating fluidized bed boiler was investigated. Based on actual operational data, a numerical simulation model for the temperature field and the stress field was established. The effects of boundary conditions, including the external heat flux density of the tube wall and the convective heat transfer coefficient, on the maximum wall temperature and maximum thermal stress of the water-wall tube, were discussed. In addition, the influences of structural parameters, such as the fin thickness and the tube pitch, on the maximum temperature difference and maximum thermal stress between adjacent water-wall tubes, were analyzed. The simulation results indicate that, under a constant convective heat transfer coefficient, both the maximum wall temperature and the maximum thermal stress of the water-wall tube will increase with the external heat flux density. Conversely, when the external heat flux density is kept constant, the maximum wall temperature and maximum thermal stress will decrease as the convective heat transfer coefficient between the tube wall and the working medium increases. Notably, when the convective heat transfer coefficient decreases to 0.5 kW/((m²·K), the maximum thermal stress will increase sharply. Furthermore, the maximum temperature difference and maximum thermal stress between adjacent water-wall tubes will increase with the decrease of the fin thickness, but increase with the tube pitch. Specifically, when the fin thickness is reduced by 2 mm, the maximum temperature difference between adjacent water-wall tubes will increase by approximately 5℃, accompanied by an increase in the maximum thermal stress from 213 MPa to 219 MPa. When the tube pitch increases by 2 mm, the maximum temperature difference will rise by about 7 ℃, and the corresponding maximum thermal stress will rise from 213.8 MPa to 215.1 MPa.
- circulating fluidized bed boiler /
- watercooled wall /
- numerical simulation /
- wall temperature /
- thermal stress

HTML全文

参考文献(25)

Yang Z, Song G, Na Y, et al. Investigation on the heat transfer coefficient and uniformity in a polygonal furnace of a 350 MW supercritical CFB boiler[J].Applied Thermal Engineering,2020,175: 115279.

[2]葛学利, 张忠孝, 范浩杰, 等. 热偏差和流量偏差对1 000 MW超超临界锅炉水冷壁壁温影响的研究[J]. 中国电机工程学报, 2018,38(8): 2348-2357.(Ge Xueli, Zhang Zhongxiao, Fan Haojie, et al. Study on the effect of thermal deviation and flow rate deviation on the wall temperature of water-cooled walls of 1 000 MW supercritical boilers[J].Proceedings of the CSEE,2018,38(8): 2348-2357. (in Chinese))

[3]李斌, 汪华剑, 梁学东, 等. 超超临界锅炉水冷壁管传热恶化对横向裂纹影响的有限元分析[J]. 中国电力, 2015,48(12): 64-69.(Li Bin, Wang Huajian, Liang Xuedong, et al. FEM analysis of heat transfer crisis of water wall tube on transverse crack in ultra-supercritical pressure boiler[J].Electric Power,2015,48(12): 64-69. (in Chinese))

[4]Fan Q, Hui S, Zhao S, et al. Thermal stress and strain distributions of a laboratory scale wall fired furnace: a numerical study and experimental verification[J].Engineering Failure Analysis,2012,25: 227-237.

[5]潘志超, 陈曦, 钟文琪, 等. 基于燃烧和汽水侧耦合数值模拟的双切圆锅炉热偏差研究[J]. 中国电机工程学报, 2023,43(22): 8801-8810.(Pan Zhichao, Chen Xi, Zhong Wenqi, et al. Thermal deviation study of double-cut circular boiler based on coupled numerical simulation of combustion and vapor side[J].Proceedings of the CSEE,2023,43(22): 8801-8810. (in Chinese))

[6]李春燕, 阎维平, 李钧, 等. 基于矩量法的超临界锅炉水冷壁温度场数值计算[J]. 中国电机工程学报, 2008,28(32): 29-34.(Li Chunyan, Yan Weiping, Li Jun, et al. Numerical calculation of water-cooled wall temperature field in supercritical boilers based on the method of moments[J].Proceedings of the CSEE,2008,28(32): 29-34. (in Chinese))

[7]Wang S, Yang D, Zhao Y, et al. Heat transfer characteristics of spiral water wall tube in a 1 000 MW ultra-supercritical boiler with wide operating load mode[J].Applied Thermal Engineering,2018,130: 501-514.

[8]范旭宸, 陈晔, 郑雄, 等. 600 MW超临界循环流化床锅炉水冷壁热应力分析[J]. 动力工程学报, 2018,38(4): 253-257. (Fan Xuchen, Chen Ye, Zheng Xiong, et al. Thermal stress analysis of water-cooled wall in a 600 MW supercritical circulating fluidized bed boiler[J].Journal of Chinese Society of Power Engineering,2018,38(4): 253-257. (in Chinese))

[9]吕太, 白杰, 董璐, 等. 燃煤电厂锅炉辐射受热面温度及热应力分析[J]. 锅炉技术, 2016,47(3): 6-11.(Lü Tai, Bai Jie, Dong Lu, et al. Temperature and thermal stress analysis of radiant heating surface of boiler in coal-fired power plant[J].Boiler Technology,2016,47(3): 6-11. (in Chinese))

[10]钱钧, 严祯荣, 王化南, 等. 超超临界锅炉垂直管圈水冷壁焊缝交错区域温度场建模及热应力模拟[J]. 动力工程学报, 2023,43(3): 307-313.(Qian Jun, Yan Zhenrong, Wang Huanan, et al. Temperature field modeling and thermal stress simulation in the staggered region of vertical tube ring water-cooled wall welds in ultra-supercritical boilers[J].Journal of Chinese Society of Power Engineering,2023,43(3): 307-313. (in Chinese))

[11]金东昊, 刘欣, 张效源, 等. 燃煤锅炉屏式过热器壁温耦合计算方法[J]. 中国电机工程学报, 2022,42(24): 8951-8960. (Jin Donghao, Liu Xin, Zhang Xiaoyuan, et al. Calculation of wall temperature coupling for screen superheaters in coal-fired boilers[J].Proceedings of the CSEE,2022,42(24): 8951-8960. (in Chinese))

[12]闫靖文, 刘欣, 黄书益, 等. 超临界锅炉水冷壁壁温预测耦合模型[J]. 热力发电, 2022,51(1): 100-108.(Yan Jingwen, Liu Xin, Huang Shuyi, et al. Coupled model for prediction of water-cooled wall temperature in supercritical boilers[J].Thermal Power Generation,2022,51(1): 100-108. (in Chinese))

[13]Zhang Z, Yang Z, Nie H, et al. A thermal stress analysis of fluid-structure interaction applied to boiler water wall[J].Asia-Pacific Journal of Chemical Engineering,2020,15(6): e2537.

[14]唐斌, 顾君苹, 张缦, 等. 350 MW超临界循环流化床锅炉水冷壁流量分配及壁温计算[J]. 煤炭学报, 2016,41(10): 2560-2567.(Tang Bin, Gu Junping, Zhang Man, et al. Calculation of water-cooled wall flow distribution and wall temperature in a 350 MW supercritical circulating fluidized bed boiler[J].Journal of China Coal Society,2016,41(10): 2560-2567.(in Chinese))

[15]袁军. 复杂环境下锅炉受热面的失效机理及寿命预测研究[D]. 北京: 华北电力大学, 2014.(Yuan Jun. Research on failure mechanism and life prediction of boiler heating surface under complex environment[D]. Beijing: North China Electric Power University, 2014. (in Chinese))

[16]王为术, 崔强, 郑梦星, 等. 350 MW超临界机组膜式水冷壁壁温计算[J]. 郑州大学学报(工学版), 2017,38(1): 46-49.(Wang Weishu, Cui Qiang, Zheng Mengxing, et al. Calculation of wall temperature of membrane water-cooled wall for 350 MW supercritical unit[J].Journal of Zhengzhou University (Engineering Science), 2017,38(1): 46-49. (in Chinese))

[17]李春燕. 超临界锅炉水冷壁管温度数值计算与研究[D]. 北京: 华北电力大学, 2009.(Li Chunyan. Numerical calculation and study of water-wall tube temperature of supercritical boiler[D]. Beijing: North China Electric Power University, 2009. (in Chinese))

[18]于涛. 超超临界CFB锅炉炉膛受热面管寿命预测研究[D]. 贵阳: 贵州大学, 2022.(Yu Tao. Study on life prediction of heating surface tubes in supercritical CFB boiler furnace[D]. Guiyang: Guizhou University, 2022. (in Chinese))

[19]Zhang X C, Gong J G, Xuan F Z. A deep learning based life prediction method for components under creep, fatigue and creep-fatigue conditions[J].International Journal of Fatigue,2021,148: 106236.

[20]庞力平, 易思泽, 段立强, 等. 灵活性运行的锅炉联箱应力分析及寿命计算[J]. 动力工程学报, 2019,39(12): 953-958. (Pang Liping, Yi Size, Duan Liqiang, et al. Stress analysis and lifetime calculation of a boiler header in flexible operation[J].Journal of Chinese Society of Power Engineering,2019,39(12): 953-958. (in Chinese))

[21]盛春红, 陈听宽. 矩形鳍片膜式水冷壁辐射角系数的求解[J]. 锅炉技术, 1997,28(8): 8-11.(Sheng Chunhong, Chen Tingkuan. Solution of radiation angle coefficients for rectangular finned membrane water-cooled walls[J].Boiler Technology,1997,28(8): 8-11. (in Chinese))

[22]于涛, 钱进, 赵威, 等. 超超临界循环流化床锅炉膜式水冷壁管温度与应力分析[J]. 热力发电, 2022,51(3): 102-108. (Yu Tao, Qian Jin, Zhao Wei, et al. Temperature and stress analysis of membrane water-cooled wall tubes in ultra-supercritical circulating fluidized bed boilers[J].Thermal Power Generation,2022,51(3): 102-108. (in Chinese))

[23]Lei D, Fu X, Ren Y, et al. Temperature and thermal stress analysis of parabolic trough receivers[J].Renewable Energy,2019,136: 403-413.

[24]郑晓红, 赵翔, 曹欣玉, 等. 锅炉高温承压部件剩余寿命的评估及应用[J]. 锅炉技术, 2003,34(4): 25-29.(Zheng Xiaohong, Zhao Xiang, Cao Xinyu, et al. Evaluation and application of residual life of high-temperature pressurized boiler components[J].Boiler Technology,2003,34(4): 25-29. (in Chinese))

[25]刘旭东, 盛伟, 关多娇, 等. 600 MW超临界锅炉膜式水冷壁的热应力分析[J]. 锅炉技术, 2010,41(6): 11-14.(Liu Xudong, Sheng Wei, Guan Duojiao, et al. Thermal stress analysis of membrane-type water-cooled walls of 600 MW supercritical boiler[J].Boiler Technology,2010,41(6): 11-14. (in Chinese))
