表面裂纹与任意杂质相互作用的半解析研究：裂纹角度、杂质材质与位置效应的系统分析

杨博政; 宋恒旭; 李璞; 金晓清

doi:10.21656/1000-0887.460204

表面裂纹与任意杂质相互作用的半解析研究：裂纹角度、杂质材质与位置效应的系统分析

doi: 10.21656/1000-0887.460204

杨博政^1,2,
宋恒旭^1,3, ,,
李璞⁴,
金晓清²

1. 中国科学院力学研究所超常环境非线性力学全国重点实验室，北京 100190;
2. 重庆大学航空航天学院，重庆 400030;
3. 中国科学院大学工程科学学院，北京 100049;
4. 四川大学空天科学与工程学院空间先进机构与智能飞行器教育部重点实验室,机器人卫星四川省国防科技重点实验室，成都 610065

基金项目:

52575201

中国科学院战略先导B类项目（XDB0620101）；国家自然科学基金（52205192

12502114）

详细信息

作者简介:
杨博政（2002—），男，博士生(E-mail: ybz468947778@163.com);宋恒旭（1988—），男，研究员，博士(通信作者. E-mail: songhengxu@imech.ac.cn).

通讯作者:
宋恒旭（1988—），男，研究员，博士(通信作者. E-mail: songhengxu@imech.ac.cn).

中图分类号: O34
计量
- 文章访问数: 19
- HTML全文浏览量: 8
- PDF下载量: 4
- 被引次数: 0
出版历程
- 收稿日期: 2025-11-17
- 修回日期: 2025-12-08
- 网络出版日期: 2026-07-30
- 刊出日期: 2026-08-01

A Semi-Analytical Study of the Interaction Between Surface Cracks and Arbitrary Inhomogeneities: Systematic Analysis of Crack Angles, Material Contrasts, and Positional Effects

Yang Bozheng^1,2,
Song Hengxu^{1,3
, ,},
Li Pu⁴,
Jin Xiaoqing²

1. State Key Laboratory of Nonlinear Mechanics, Institute of Mechanics, Chinese Academy of Science, Beijing 100190, P.R. China;
2. College of Aerospace Engineering, Chongqing University, Chongqing 400030, P.R. China;
3. School of Engineering Science, University of Chinese Academy of Sciences, Beijing 100049, P.R. China;
4. Key Laboratory of Advanced Spatial Mechanism and Intelligent Spacecraft (Ministry of Education), Robotic Satellite Key Laboratory of Sichuan Province, School of Aeronautics and Astronautics, Sichuan University, Chengdu 610065, P.R. China

Funds:

52575201

The National Science Foundation of China(52205192

12502114)

摘要

摘要: 本文围绕半平面中表面裂纹与任意形状杂质的相互作用行为，基于数值等效夹杂法与分布位错技术构建了统一的半解析求解框架，并通过一系列算例系统评估了裂纹角度、杂质材质以及杂质位置对应力强度因子与局部应力场的影响规律.算例结果表明：裂纹角度的变化会显著改变裂尖附近的应力分布特征，倾斜裂纹产生更强的模式耦合；杂质材质对相互作用效应高度敏感，硬质杂质使Ⅰ型应力强度因子减小、Ⅱ型应力强度因子增大，而软质杂质则表现出相反趋势；随着杂质逐渐远离自由边界，其对裂尖的扰动作用明显减弱.所有算例的半解析计算结果均与有限元解保持良好一致，应力强度因子误差小于4.5%，验证了所建半解析框架的可靠性.上述算例研究揭示了多因素耦合作用下裂纹杂质相互作用的主要规律，可为复杂材料与结构中损伤演化机理的分析提供有价值的参考.
- 表面裂纹 /
- 杂质 /
- 半解析方法 /
- 应力强度因子
Abstract: A unified semi-analytical framework combining the numerical equivalent inclusion method (NEIM) and the distributed dislocation technique (DDT) was employed to investigate the interaction between surface cracks and arbitrarily shaped inhomogeneities in a half-plane. Several representative examples were simulated to systematically examine the effects of crack angles, inhomogeneity stiffnesses, and the inhomogeneity distances from the free surface on the stress intensity factors and local stress fields. The results show that, the crack angle leads to notable changes in the crack-tip field and induces pronounced mode coupling. Stiff inhomogeneities decrease Mode Ⅰ stress intensity factor but increase Mode Ⅱ, whereas soft inhomogeneities exhibit the opposite trend. As the inhomogeneity moves farther from the free surface, its perturbation to the crack-tip field becomes significantly weaker. The semi-analytical results agree well with the finite element solutions, with discrepancies below 4.5%, demonstrating the accuracy and efficiency of the present framework. The numerical examples provide clear insight into the dominant mechanisms governing crack-inhomogeneity interaction under multiple influencing parameters.
- surface crack /
- inhomogeneity /
- semi-analytical method /
- stress intensity factor

HTML全文

参考文献(28)

Guan J, Wang L, Zhang C, et al. Effects of non-metallic inclusions on the crack propagation in bearing steel[J].Tribology International,2017,106: 123-131.

[2]Tamate O. The effect of a circular inclusion on the stresses around a line crack in a sheet under tension[J].International Journal of Fracture Mechanics,1968,4(3): 257-266.

[3]Muskhelishvili N I.Some Basic Problems of the Mathematical Theory of Elasticity[M]. Groningen: P. Noordhoff, 1963.

[4]Gdoutos E E. Interaction effects between a crack and a circular inclusion[J].Fibre Science and Technology,1981,15(3): 173-185.

[5]Eshelby J D. The determination of the elastic field of an ellipsoidal inclusion, and related problems[J].Proceedings of the Royal Society of London Series A: Mathematical and Physical Sciences,1957,241(1226): 376-396.

[6]Jin X, Wang Z, Zhou Q, et al. On the solution of an elliptical inhomogeneity in plane elasticity by the equivalent inclusion method[J].Journal of Elasticity,2014,114(1): 9423.

[7]Li P, Lyu D, Soewardiman H, et al. Analytical and numerical evaluation of the interaction energy between screw dislocation and inhomogeneous inclusion[J].Mechanics of Materials,2021,156: 103788.

[8]Jin X, Zhang X, Li P, et al. On the displacement of a two-dimensional Eshelby inclusion of elliptic cylindrical shape[J].Journal of Applied Mechanics,2017,84(7): 074501.

[9]Jin X, Keer L M, Wang Q. A closed-form solution for the Eshelby tensor and the elastic field outside an elliptic cylindrical inclusion[J].Journal of Applied Mechanics,2011,78(3): 031009.

[10]Li Z, Chen Q. Crack-inclusion interaction for mode Ⅰ crack analyzed by Eshelby equivalent inclusion method[J].International Journal of Fracture,2002,118(1): 29-40.

[11]Yang L, Chen Q, Li Z. Crack-inclusion interaction for mode Ⅱ crack analyzed by Eshelby equivalent inclusion method[J].Engineering Fracture Mechanics,2004,71(9/10): 1421-1433.

[12]Lal A, Vaghela M B, Mishra K. Numerical analysis of an edge crack isotropic plate with void/inclusions under different loading by implementing XFEM [J].Journal of Applied Computational Mechanics,2019,7(3): 1362-1382.

[13]Li R, Wu S, Ivanova E, et al. Finite element model and experimental analysis of crack-inclusion interaction[J].Journal of Applied Polymer Science,1993,50(7): 1233-1238.

[14]Lipetzky P, Schmauder S. Crack-particle interaction in two-phase composites, part Ⅰ: particle shape effects[J].International Journal of Fracture,1994,65(4): 345-358.

[15]Nguyen T T, Yvonnet J, Zhu Q Z, et al. A phase-field method for computational modeling of interfacial damage interacting with crack propagation in realistic microstructures obtained by microtomography[J].Computer Methods in Applied Mechanics and Engineering,2016,312: 567-595.

[16]Kumar A, Sain T. A unified thermo-viscoelastic phase-field fracture model for fiber-reinforced polymer composites[J].Journal of the Mechanics and Physics of Solids,2026,206: 106378.

[17]Bian P L, Liu Q, Zhang H, et al. Adaptive phase-field cohesive-zone model for simulation of mixed-mode interfacial and bulk fracture in heterogeneous materials with directional energy decomposition[J].Computer Methods in Applied Mechanics and Engineering,2025,443: 118062.

[18]Hills D A, Kelly P, Dai D, et al.Solution of Crack Problems: the Distributed Dislocation Technique[M]. Springer Science & Business Media, 1996.

[19]Yang B, Li P, Liu K, et al. Analysis of kinked cracks interacting with multiple inhomogeneities[J].International Journal of Mechanical Sciences,2025,304: 110703.

[20]Yang B, Li P, Liu K, et al. Semi-analytical modeling of coating-crack-defect interactions using a combined distributed dislocation technique and numerical equivalent inclusion method[J].Tribology International,2026,214: 111199.

[21]Eshelby J D. The elastic field outside an ellipsoidal inclusion[J].Proceedings of the Royal Society of London Series A: Mathematical and Physical Sciences,1959,252(1271): 561-569.

[22]Zhou Q, Jin X, Wang Z, et al. Numerical implementation of the equivalent inclusion method for 2D arbitrarily shaped inhomogeneities[J].Journal of Elasticity,2015,118(1): 39-61.

[23]Zhou Q, Jin X, Wang Z, et al. Numerical EIM with 3D FFT for the contact with a smooth or rough surface involving complicated and distributed inhomogeneities[J].Tribology International,2016,93: 91-103.

[24]金晓清, 牛飞飞, 张睿, 等. 均布激励基本单元解析解的一种记号方法[J]. 上海交通大学学报, 2016,50(8): 1221-1227.(Jin Xiaoqing, Niu Feifei, Zhang Rui, et al. A notation for elementary solution to uniformly distributed excitation over a rectangular/cuboidal domain[J].Journal of Shanghai Jiao Tong University,2016,50(8): 1221-1227. (in Chinese))

[25]谢东东, 金晓清, 蒋志桢, 等. 弹性半平面矩形夹杂基本单元解及其应用[J]. 重庆大学学报, 2022,45(12): 26-35.(Xie Dongdong, Jin Xiaoqing, Jiang Zhizhen, et al. Elementary solution of the elastic half-plane containing a rectangular inclusion: theory and applications[J].Journal of Chongqing University,2022,45(12): 26-35. (in Chinese))

[26]Liu K, Li P, Yang B, et al. Cuboidal inclusion problem revisited: unified expressions for the complete elastic fields and numerical implementation based on FFT[J].Tribology International,2026,213: 111099.

[27]Liu K, Li P, Yang B, et al. A versatile three-dimensional contact analysis for heterogeneous materials[J].International Journal of Solids and Structures,2025,318: 113440.

[28]Zhou K, Keer L M, Wang Q J. Semi-analytic solution for multiple interacting three-dimensional inhomogeneous inclusions of arbitrary shape in an infinite space[J].International Journal for Numerical Methods in Engineering,2011,87(7): 617-638.
